品牌：藍江/LAND
材料：尼龍6
溫度：-40°C-105°C
環保：符合ROHS2.0標準
性能：90度彎角設計，可同時鎖緊波紋管與電纜，軟管與電纜可同時達到IP68防護
應用：機床，照明，安防門禁，軌道交通，機器人等
藍江產品型號 | 螺紋規格 | 電纜范圍 | 適配軟管 | 螺紋長度 | 扳手尺寸 |
Product model | Thread size | Cable range | Adapter hose | Thread length | Wrench Size |
PN. | Metric | φ mm | AD mm | GL mm | nut/cap mm |
RGW13.0-MG12-08 | M12×1.5 | 4～8 | AD13.0 | 8 | 17/16 |
RGW13.0-MG12-05 | M12×1.5 | 3～5.5 | AD13.0 | 8 | 17/16 |
RGW13.0-MG12-03 | M12×1.5 | 1.5～3 | AD13.0 | 8 | 17/16 |
RGW15.8-MG16-10 | M16×1.5 | 6～10 | AD15.8 | 10 | 22/22 |
RGW15.8-MG16-07 | M16×1.5 | 4～7 | AD15.8 | 10 | 22/22 |
RGW15.8-MG16-05 | M16×1.5 | 3～5 | AD15.8 | 10 | 22/22 |
RGW15.8-MG16-04 | M16×1.5 | 2～4 | AD15.8 | 10 | 22/22 |
RGW21.2-MG20-14 | M20×1.5 | 8～14 | AD21.2 | 15 | 27/27 |
RGW21.2-MG20-11 | M20×1.5 | 6～11 | AD21.2 | 15 | 27/27 |
RGW21.2-MG20-09 | M20×1.5 | 5～9 | AD21.2 | 15 | 27/27 |
RGW25.0-MG25-18 | M25×1.5 | 13～18 | AD25 | 15 | 33/33 |
RGW25.0-MG25-16 | M25×1.5 | 11～16 | AD25 | 15 | 33/33 |
RGW25.0-MG25-14 | M25×1.5 | 8～14 | AD25 | 15 | 33/33 |
RGW25.0-MG25-10 | M25×1.5 | 6～10 | AD25 | 15 | 33/33 |
RGW28.5-MG25-18 | M25×1.5 | 13～18 | AD28.5 | 15 | 33/33 |
RGW28.5-MG25-16 | M25×1.5 | 11～16 | AD28.5 | 15 | 33/33 |
RGW28.5-MG25-14 | M25×1.5 | 8～14 | AD28.5 | 15 | 33/33 |
RGW28.5-MG25-10 | M25×1.5 | 6～10 | AD28.5 | 15 | 33/33 |
RGW34.5-MG32-25 | M32×1.5 | 18～25 | AD34.5 | 15 | 41/41 |
RGW34.5-MG32-22 | M32×1.5 | 16～22 | AD34.5 | 15 | 41/41 |
RGW42.5-MG40-31 | M40×1.5 | 24～31 | AD42.5 | 20 | 50/50 |
RGW42.5-MG40-25 | M40×1.5 | 18～25 | AD42.5 | 20 | 50/50 |
RGW54.5-MG50-41 | M50×1.5 | 35～31 | AD54.5 | 20 | 50/50 |
RGW54.5-MG50-33 | M50×1.5 | 25～33 | AD54.5 | 20 | 50/50 |
RGW21.2-G1/2-14 | G1/2 | 8～14 | AD21.2 | 15 | 27/27 |
RGW21.2-MG20-11 | G1/2 | 6～11 | AD21.2 | 15 | 27/27 |
RGW21.2-G1/2-09 | G1/2 | 5～9 | AD21.2 | 15 | 27/27 |
